QGIS GUI

When QGIS starts, you are presented with the GUI as shown in the figure (the numbers 1 through 5 in yellow circles are discussed below).

Figure QGIS GUI 1:

../../../_images/startup.png

QGIS GUI with Alaska sample data nix

Catatan

Jendela dekorasi Anda (judul bar , dll) dapat terlihat berbeda tergantung pada sistem operasi dan window manager Anda .

The QGIS GUI is divided into five areas:

  1. Bar Menu

  2. Tool Bar
  3. Map Legend
  4. Tampilan Peta

  5. Status Bar

These five components of the QGIS interface are described in more detail in the following sections. Two more sections present keyboard shortcuts and context help.

Toolbar

Toolbar menyediakan akses ke sebagian besar fungsi yang sama seperti menu, ditambah alat tambahan untuk berinteraksi dengan peta. Setiap item toolbar memiliki popup bantuan yang tersedia. Tahan tetikus anda ke atas item dan deskripsi singkat mengenai tujuan alat itu akan ditampilkan.

Every menu bar can be moved around according to your needs. Additionally, every menu bar can be switched off using your right mouse button context menu, holding the mouse over the toolbars (read also Panels and Toolbars).

Tip

Mengembalikan toolbar

If you have accidentally hidden all your toolbars, you can get them back by choosing menu option Settings ‣ Toolbars ‣. If a toolbar disappears under Windows, which seems to be a problem in QGIS from time to time, you have to remove key \HKEY_CURRENT_USER\Software\QGIS\qgis\UI\state in the registry. When you restart QGIS, the key is written again with the default state, and all toolbars are visible again.

Map Legend

The map legend area lists all the layers in the project. The checkbox in each legend entry can be used to show or hide the layer. The Legend toolbar in the map legend are list allow you to Add group, Manage Layer Visibility of all layers or manage preset layers combination, Filter Legend by Map Content, Expand All or Collapse All and Remove Layer or Group.

Figure Layer tools Bar:

../../../_images/layer_toobar.png

Layer Tool Bar in Map Legend nix

The button mActionShowPresets allows you to add Presets views in the legend. It means that you can choose to display some layer with specific categorization and add this view to the Presets list. To add a preset view just click on mActionShowPresets, choose Add Preset... from the drop down menu and give a name to the preset. After that you will see a list with all the presets that you can recall pressing on the mActionShowPresets button.

All the added presets are also present in the map composer in order to allow you to create a map layout based on your specific views (see Main properties).

Suatu lapisan (layer) dapat dipilih dan digeser ke atas atau kebawah pada legenda menjadi Z-urutan. Z-urutan berarti bahwa lapisan yang terdaftar di bagian atas legenda digambar lapisan bawahnya tercantum dalam legenda.

Catatan

This behaviour can be overridden by the ‘Layer order’ panel.

Layers in the legend window can be organised into groups. There are two ways to do this:

  1. Press the mActionFolder icon to add a new group. Type in a name for the group and press Enter. Now click on an existing layer and drag it onto the group.
  2. Pilih beberapa lapisan (layer), klik kanan pada jendela legenda dan pilih Grup Terpilih. Lapisan-lapisan yang dipilih secara otomatis akan menjadi satu grup baru.

Untuk mengeluarkan lapisan dari grup, Anda bisa menggesernya keluar, atau klik kanan dan pilih Ubah jadi tingkat teratas. Grup dapat masuk kedalam grup lain.

Kotak centang grup akan memunculkan atau menyembunyikan lapisan dalam grup dengan satu klik.

The content of the right mouse button context menu depends on whether the selected legend item is a raster or a vector layer. For GRASS vector layers, mActionToggleEditing Toggle editing is not available. See section Digitizing and editing a GRASS vector layer for information on editing GRASS vector layers.

Right mouse button menu for raster layers

  • Zoom to Layer
  • Show in overview
  • Zoom to Best Scale (100%)
  • Remove
  • Duplicate
  • Set Layer Scale Visibility
  • Set Layer CRS
  • Atur CRS Proyek dari Lapisan

  • Styles ‣
  • Save as ...
  • Save As Layer Definition File ...
  • Properti

  • Ubah Nama

Additionally, according to layer position and selection

  • Move to Top-level
  • Grup dipilih

Right mouse button menu for vector layers

  • Zoom to Layer
  • Show in overview
  • Remove
  • Duplicate
  • Set Layer Scale Visibility
  • Set Layer CRS
  • Atur CRS Proyek dari Lapisan

  • Styles ‣
  • Open Attribute Table
  • Toggle Editing (not available for GRASS layers)
  • Save As ...
  • Save As Layer Definition Style
  • Saring

  • Show Feature Count
  • Properti

  • Ubah Nama

Additionally, according to layer position and selection

  • Move to Top-level
  • Grup dipilih

Right mouse button menu for layer groups

  • Zoom to Group
  • Remove
  • Set Group CRS
  • Ubah Nama

  • Add Group

Saat ini memungkinkan memilih lebih dari satu lapisan atau grup pada waktu yang sama dengan menekan tombol Ctrl sambil memilih lapisan dengan tombol kiri tetikus. Kemudian Anda dapat memindah semua lapisan terpilih ke dalam grup baru pada waktu yang sama.

You may also delete more than one layer or group at once by selecting several layers with the Ctrl key and pressing Ctrl+D afterwards. This way, all selected layers or groups will be removed from the layers list.

Bekerja dengan Legenda urutan lapisan tersendiri

There is a panel that allows you to define an independent drawing order for the map legend. You can activate it in the menu Settings ‣ Panels ‣ Layer order. This feature allows you to, for instance, order your layers in order of importance, but still display them in the correct order (see figure_layer_order). Checking the checkbox Control rendering order box underneath the list of layers will cause a revert to default behavior.

Figure Layer Order:

../../../_images/layer_order.png

Define a legend independent layer order nix

Tampilan Peta

This is the “business end” of QGIS — maps are displayed in this area! The map displayed in this window will depend on the vector and raster layers you have chosen to load (see sections that follow for more information on how to load layers). The map view can be panned, shifting the focus of the map display to another region, and it can be zoomed in and out. Various other operations can be performed on the map as described in the toolbar description above. The map view and the legend are tightly bound to each other — the maps in view reflect changes you make in the legend area.

Tip

Perbesar peta dengan tetikus

Anda dapat menggunakan tetikus untuk memperbesar dan memperkecil peta. Tempatkan kursor tetikus di dalam area peta dan roll roda depan (jauh dari Anda) untuk memperbesar dan belakang (ke arah Anda) untuk memperkecil. Posisi kursor tetikus adalah pusat di mana perubahan terjadi. Anda dapat menyesuaikan perilaku pembesaran roda tetikus menggunakan menu Alat Peta dalam menu Pengaturan ‣ Opsi.

Tip

Menggeser peta dengan tombol panah dan spasi bar

Anda dapat menggunakan tombol panah untuk menggeser peta. empatkan kursor tetikus dalam area peta dan klik panah kanan untuk menggeser ke Timur, panah kiri untuk menggeser ke Barat, panah atas untuk menggeser ke Utara dan pana bawah untuk menggeser ke Selatan. Anda juga dapat menggeser peta dengan menggunakan bar spasi atau klik pada tetikus: hanya menggerakkan tetikus bersamaan menekan bar spasi atau klik tetikus.

Status Bar

The status bar shows you your current position in map coordinates (e.g., meters or decimal degrees) as the mouse pointer is moved across the map view. To the left of the coordinate display in the status bar is a small button that will toggle between showing coordinate position or the view extents of the map view as you pan and zoom in and out.

Next to the coordinate display you will find the scale display. It shows the scale of the map view. If you zoom in or out, QGIS shows you the current scale. There is a scale selector, which allows you to choose between predefined scales from 1:500 to 1:1000000.

To the right of the scale display you can define a current clockwise rotation for your map view in degrees.

A progress bar in the status bar shows the progress of rendering as each layer is drawn to the map view. In some cases, such as the gathering of statistics in raster layers, the progress bar will be used to show the status of lengthy operations.

If a new plugin or a plugin update is available, you will see a message at the far left of the status bar. On the right side of the status bar, there is a small checkbox which can be used to temporarily prevent layers being rendered to the map view (see section Rendering below). The icon mIconStopRendering immediately stops the current map rendering process.

To the right of the render functions, you find the EPSG code of the current project CRS and a projector icon. Clicking on this opens the projection properties for the current project.

Tip

Menghitung skala koreksi dari kanvas peta Anda

When you start QGIS, the default units are degrees, and this means that QGIS will interpret any coordinate in your layer as specified in degrees. To get correct scale values, you can either change this setting to meters manually in the General tab under Settings ‣ Project Properties, or you can select a project CRS clicking on the mIconProjectionDisabled Current CRS: icon in the lower right-hand corner of the status bar. In the last case, the units are set to what the project projection specifies (e.g., ‘+units=m’).
